20KVA Escort Diesel Gensets

Name: 20KVA Escort Diesel Gensets
Brand: A.B. SERVICES
Price: 296202 INR
Availability: InStock

Price 296202 INR/ Number

Get a Price/Quote

MOQ : 1 Set

20KVA Escort Diesel Gensets Specification

Alternator
Brushless, Self Excited

Fuel Consumption
4.5 L/hr (at 75% Load)

Engine Model
Escort 415D

Standard
ISO 9001:2015 Certified

Insulation
Class H

Pressure
17.5:1 Compression Ratio

Protection Class
IP23

Fuel Tank Capacity
60 Liters

Poles Number
4

Bore *Stroke
104 mm x 113 mm

Dimension (L*W*H)
2200 mm x 950 mm x 1350 mm

Engine Type
4 Stroke, Water Cooled, Direct Injection

Product Type
Diesel Generator

Output Type
AC Three Phase

Rated Power
20 KVA

Rated Voltage
415 V

Starting Type
Electric Start

Rated Frequency
50 Hz

Power Range
20 KVA

Color
Green and White

Cooling System
Water Cooled

Noise Level
Silent / Low Noise

Phase
Three Phase

Speed
1500 RPM

Weight
Approx. 900 kg

Emission Compliance
CPCB II Norms

Overload Capacity
110% for 1 hour

Lubricating Oil Capacity
7.5 Liters

Battery Capacity
12V, 88Ah

Control Panel
Digital/Auto Mains Failure (AMF) Panel

Canopy
Acoustic Enclosure, Powder Coated

Control Features
Digital Metering, Safety Shutdowns, Remote Start

Voltage Regulation
±1% (With AVR)

Alternator Make
Stamford/Kirloskar

Engine Cooling
Radiator Cooled with Coolant

Frequency Tolerance
±0.5 Hz

About 20KVA Escort Diesel Gensets

Grab the top-rated and hot-selling 20KVA Escort Diesel Gensets, crafted for imposing performance in demanding environments. Featuring an invincible digital/Auto Mains Failure (AMF) panel, impeccable voltage regulation (1% with AVR), and peerless emission compliance (CPCB II Norms), this genset ensures seamless power backup with every use. Its sturdy radiator-cooled engine, robust acoustic enclosure, and effortless electric start give you reliable, silent operation every time. Choose the dependable supplier and service provider for maximum assurance-distributed widely across India for world-class service and quality.

Feature Highlights, Application, and Usage

Escort 20KVA Diesel Gensets boast advanced features: digital metering, remote start, and overload resilience (110% for one hour). The user-friendly digital/AMF control panel ensures simple operation. Perfectly suited for industrial plants, offices, hospitals, and commercial complexes, these gensets provide continuous, silent power backup. Installation is straightforward-position on a flat, ventilated site, connect to three-phase AC supply, and charge with recommended diesel for superior output.

Export Markets, Pricing, and Certifications

Escort 20KVA Diesel Gensets are dispatched at the lowest price from India's major FOB ports, catering to global markets including Africa, Southeast Asia, and Middle East. Each unit is ISO 9001:2015 certified, ensuring world-class reliability. Experience rapid charge and swift dispatching with guaranteed quality in every export batch, making this genset a trusted solution for international users seeking robust backup and unbeatable value.

Rating	20KVA	20KVA
Power Factor (PF)	0.8 (lag)	0.8 (lag)
Engine Model	G 15 - II	G 20 - II
Engine Rating (KW)	16	16
Cooling type	Water Cooled	Water Cooled
Cylinders	2	3
Gross Power (BHP)	22	25
Bore and stroke (mm)	95 x 110	91 x 110
Displacement (Litres)	1.56	2.145
Compression Ratio	17.5:01	17.5:01
Lube Oil Sump capacity (Litres)	5	6.5
Lube Oil Consumtion (liters/hours)	0.1	0.1
Coolant Capacity (Litres)	7.0	7.5
Services Invervel (Hours/Months)	500/12	500/12
Governing type	Mechnical (A1)	Mechnical (A1)
Air Cleaner type	Dry	Dry
Method of starting - Electrical	12V DC	12V DC
Minimum capacity of Amp.hr starting BATTERY	90	90
Alternator Make	Stamford/ Leory Somer/ Mecc Alte (Depends on avaikability)	Stamford/ Leory Somer/ Mecc Alte (Depends on avaikability)
Alternator type	Brushless, Single bearing, Self-excited with solid state AVR	Brushless, Single bearing, Self-excited with solid state AVR
Frequency (Hz)	50	50
Insulation Class	F/H	F/H
Control panel (Mode)	standard control panel / AMF optional	standard control panel / AMF optional
Genset dimensions (LXBXH)	1800X1000X1250	2000X1000X1350
Fuel Tank Capacity (Litres)	40	60

FAQ's of 20KVA Escort Diesel Gensets:

Q: How does the Auto Mains Failure (AMF) panel operate on the 20KVA Escort Diesel Genset?

A: The AMF panel automatically detects mains power outages and initiates the generator to ensure uninterrupted power supply. Once grid power is restored, it seamlessly switches back, providing hassle-free operation.

Q: What distinct features make this genset suitable for industrial and commercial sites?

A: Key features include 1% voltage regulation with AVR, remote start, overload capacity, silent acoustic enclosure, and CPCB II emission compliance, ensuring dependable performance in diverse environments.

Q: Where should the 20KVA Escort Diesel Genset be installed for optimal efficiency?

A: Install the genset on a stable, flat surface in a well-ventilated area, away from residential zones to maximize cooling efficiency and noise attenuation. Always follow safety standards during site placement.

Q: When is it recommended to service the genset, and what are typical intervals?

A: Servicing should be performed every 500 hours of operation or at twelve-month intervals, as per manufacturer guidelines, to maintain peak efficiency and longevity.

Q: What is the process for starting and operating the genset?

A: The generator features an electric start. After ensuring fuel, oil, and coolant levels are adequate, simply engage the starter switch. The digital control panel manages metering and safety shutdowns automatically.

Q: How can users benefit from the CPCB II and ISO 9001:2015 certifications of this genset?

A: These certifications guarantee compliance with strict emission norms and quality standards, offering users eco-friendly operation, reliability, and assurance recognized in both domestic and export markets.
